BCP High Pressure CCC CQC UL Energy Star Certification Protection Level IP65 100W 225W 160W 200W Explosion Proof Platform Lamp

FOB Reference Price:Get Latest Price
$43.00 - $237.00 / Pieces | 1 Piece/Pieces (Min. Order)
Report Suspicious Activity
Overview
Quick Details
Input Voltage(V):
220
Lamp Power(W):
100
CRI (Ra>):
80
Lamp Luminous Flux(lm):
6000
Working Lifetime(Hour):
50000
Working Temperature(℃):
-25 - +55
Place of Origin:
Zhejiang, China (Mainland)
Brand Name:
TNDACN
Model Number:
BCP
Light Source Type:
Z; B; G; N; L; Y; H; E; M;
Anti-corrosion:
WF1
Temperature Class:
T1-T6
Cable outer dia(mm):
10-14
rated current:
0.23A
Wire inlet:
G3/4"
EX-mark:
ExdembIICT4
Ex rating dust:
DIP A20 TA,T4/T3
Ex rating gas:
ExnR II T4 Gb, ExnR II T3Gb
Standards:
GB3836, IEC60079, EN61241
Item Type:
Explosion-proof Lights
IP Rating:
IP65
Light Source:
Incandescent Bulbs
Color Temperature(CCT):
COOL WHITE
Base Type:
E27
Certification:
CCC, CQC, Energy Star, UL
Lamp Body Material:
Aluminum Alloy
Lamp Luminous Efficiency(lm/w):
60
Supply Ability
Supply Ability:
10000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Cartons,Wooden cases or others as you are required.
Port
Ningbo or Shanghai
Lead Time :
Shipped in 10 days after payment
Product Description
Applications

1.Hazardous:division 1 &2,or 20,21,&22;

2.Explosive gas atmosphers: classⅡA ⅡB ⅡC or inflammable dust environment;

3.Indoor or outdoor(IP54,IP65*);

4.Temperature class:T1~T4/T5/T6;

5. Can be used in the chemical, petroleum refining, petroleum exploitation, offshore platform, tankers, military industry and other dangerous places.

Features

1.The enclosure is cast with aluminium alloy or strecthed by stainless steel stretching and SMC or DMC extruding, Surfaceis sprayed with plastic;

2.The steel tube is galvanized and the surface of lamp pole is sprayed with plastic;

3.Frank and bend rod type adopts welded connection;

4.Wiring with steel tube or cable.
